Larger
|
|
Induction
Motor
|
Features
The AC INDUCTION MOTOR first be used
in miter saw with Chinese patent
Powerful 7 AMP AC INDUCTION motor
Special AC INDUCTION MOTOR, Work
with low noise for environmental protection
No
carbon brush and no gear for long life
Bevel cuts
up to 45¡ã
to the left
Miter cuts
0-50¡ãleft
and 0-50¡ãright
Weighs only
16.5 kgs. for easy portability
Precision
machined aluminum base ensures accurate cuts
Performs
compound cutting operations
Positive
stops at ,22
5¡ã ,
45¡ã , right
or left and 0¡ã(90¡ãcuts)
Standard Equipment (Includes)
Socket wrench
Work Rest
Ext Brace
Available Virench
Dust bag
Hex Key
| Specifications |
|
|
| Volt |
|
220V
|
| AMPS
(220V) |
|
7
A
|
| Continuous
Rating Input |
|
1600W
|
| No
load speed |
|
3000
RPM
|
| Blade
Diameter |
|
12
" ( 305mm )
|
| Arbor
|
|
1
" ( 25.4mm )
|
| Net
Weight |
|
16.5
Kgs
|
| Bevel
Stops |
|
0°,45°
|
| Miter
Angle Range |
|
50°Left/
50°Right
|
| Positive
Miter Detent Stops |
|
0°,
22.5°,45°
|
| Max.
cutting capacities |
at 90° |
110x130
mm
|
|
at 45° |
110x
95 mm
|
|
|
|
|
|
