Larger
|
Induction
Motor
|
Features
The AC INDUCTION MOTOR first be used
in miter saw with Chinese patent
Powerful 7 AMP AC INDUCTION motor
Special AC INDUCTION MOTOR, Work
with low noise for environmental protection
No
carbon brush and no gear for long life
Bevel cuts
up to 45²ã
to the left
Miter cuts
0-50²ãleft
and 0-50²ãright
Weighs only
15 kgs. for easy portability
Precision
machined aluminum base ensures accurate cuts
Performs
compound cutting operations
Positive
stops at :22
5²ã ,
45²ã , right
or left and 0²ã(90²ãcuts)
Standard Equipment (Includes)
Socket wrench
Work Rest
Ext Brace
Available Virench
Dust bag
Hex Key
Specifications |
|
|
Volt |
|
220V
|
AMPS
(220V) |
|
7
A
|
Continuous
Rating Input |
|
1600W
|
No
load speed |
|
3000
RPM
|
Blade
Diameter |
|
10
" ( 255mm )
|
Arbor
|
|
1
" ( 25.4mm )
|
Net
Weight |
|
15
Kgs
|
Bevel
Stops |
|
0°,45°
|
Miter
Angle Range |
|
50°Left/
50°Right
|
Positive
Miter Detent Stops |
|
0°,
22.5°,45°
|
Max.
cutting capacities |
at 90° |
68x140
mm
|
|
at 45° |
68x105
mm
|
|
|
|
|
